eCA series / Ultra-Compact Amplifiers

eCA120HZ

Name: Ecler eCA120HZ
Brand: Ecler
SKU: eCA120HZ

120W@100V | mono | micro-amplifier

eCA120HZ is a mono micro-amplifier delivering 1 x 106W RMS @ 70V / 100 V line level (high impedance), built in a very compact format and a light and silent (fanless) design. It features 1 LINE stereo input, AUTO STANDBY function and volume remote control, compatible with ECLER WPaVOL and WPaVOL-SR wall panels (0-10 VDC). External, universal and CE/UL/CCC certified power supply.

Request a quote →Chat on Zalo

Key features

011 x 106W RMS @ 70V / 100V line level (high impedance) amplifier

02External, universal power supply

03AUTO STANDBY function: in the absence of an audio signal the unit automatically goes into STANDBY mode, minimizing power consumption

04Light and silent (fanless) design

051 unbalanced stereo line input (LINE IN / STACK), with dual RCA connector and 3-pin Euroblock connector

06Local volume control by knob

07Remote volume control by WPa series wall panel (0-10VDC)

CHANNELS

Number of output channels: 1
Output connection type: Euroblock
Output configuration: 1 x 106W RMS @ 70V / 100V line level (high impedance) amplifier
Number of input channels: 1
Input connection type: Dual RCA and 3-pin Euroblock
Input configuration: LINE / STACK input

OUTPUT POWER - All channels driven @ 1%THD

Max output power @ 100V: 106 W @ 100Ω

SIGNAL

Input sensitivity: 0dBV
Input impedance: >20kΩ
Frequency response: 70Hz - 30kHz (-3dB)
THD + Noise: SPKR OUT < 0.07% @ 1kHz
SNR: >85dB (VOLUME at 0dB)
Crosstalk: >65dB @ 1kHz

ELECTRICAL

Power supply: External, universal power supply
AC mains requirement: 100-240 V @ 50-60Hz + External PSU 24VDC
AC mains connector: DC24V power connector

POWER CONSUMPTION

Power Consumption (1/3 POWER, @ 4Ω all channels driven): pink noise, 51W / 61VA
Power Consumption (1/8 POWER, @ 4Ω all channels driven): pink noise, 26W / 38VA
Power Consumption (STBY/SLEEP): <2.5W

TECHNOLOGIES

Energy saving: Auto standby function
Cooling: Convection (fanless)

PROTECTIONS

AC protection: No
DC protection: No
VHF protection: No
Short-circuit protection: No
Clip limiter: No
Long term limiter: No
Thermal protection: No

REMOTE CONTROL CONNECTIONS

GPIs: x1 GPI (0-10VDC) for volume control

SETTINGS

Attenuators: Front panel knob
Filters: 70Hz High Pass Filter (internal, not removable)
Output settings: 70V/100V outputs
Auto standby function: Front panel jumper
Auto standby threshold: -40dBV (L&R)
Auto standby time: 120 seconds

MONITORING

Signal Present: SP LED (Green)
Cliping: CLIP LED (Red)
Standby: STBY LED (Orange)

PHYSICAL

Operating temperature: Min: -10°C ; 14°F Max: 40°C ; 104°F
Operating humidity: <85% HR
Storage temperature: Min: -10°C ; 14°F Max: 40°C ; 104°F
Storage humidity: <90% HR
Installation options: Wall or under a surface (table, shelf, cupboard, etc.)
Optional accessories: WPaVOL series for remote control
Dimensions: 190 x 48 x 190 mm / 7.48 x 1.89 x 7.48 in. (WxHxD) (knobs and connectors excluded)
Weight: 2.3 kg / 5.07 lb
Shipping dimensions: 340 x 60 x 220 mm / 13.39 x 2.36 x 8.66 in. (WxHxD)
Shipping weight: 3.1 kg / 6.83 lb
