Schijnel, The Netherlands
Splitters
VEO-SPH44
1x4 HDMI® Splitter
VEO-SPH44 is a 1×4 HDMI® splitter for high dynamic range (HDR) formats. Simultaneously displays an UItra Hi-Definition source on up to two UItra HD displays.
Key features
01Supports resolutions up to UItra HD 4Kx2K(4096x2160@60Hz YUV 4:4:4 )
02Three EDID setting modes
03HDCP2.2/1.4 Compliant
04Supports 36 bit Deep Color
05Supports LPCM 7.1, Dolby TrueHD, Dolby digital Plus, and DTS-HD Master Audio
06Supports HDR and 3D contents
07Supports up to 18Gbps video data rate
08Front panel LED indicators for power and signal status
VIDEO PERFOMANCES
- Video Input Connectors
- 1 HDMI® Type A Female, 2.0, 18 Gbps
- Video Output Connectors
- 4 HDMI® Type A Female, 2.0, 18 Gbps
- Video Input Resolutions
- Up to 4096x2160@60Hz 4096x2160@24/25/30/50/60Hz, 3840x2160@24/25/30/50/60Hz,2048x1080p 1080p@23.98/24/25/29.97/30/50/59.94/60Hz,1080i@50/59.94/60Hz,720p@50/59.94/60Hz, 576p, 576i, 480p, 480i
- Video Output Resolutions
- Up to 4096x2160@60Hz 4096x2160@24/25/30/50/60Hz, 3840x2160@24/25/30/50/60Hz,2048x1080p 1080p@23.98/24/25/29.97/30/50/59.94/60Hz,1080i@50/59.94/60Hz,720p@50/59.94/60Hz, 576p, 576i, 480p, 480i
- Chroma Subsampling
- 4:4:4, 4:2:2, 4:2:0
- Colour Depth
- 8-bit, 10-bit, 12-bit
- Colour Space
- RGB, YCbCr
- HDCP
- 2.2/1.4 Compliant
- HDR
- HDR 10
- HDMI® Distance
- up to 10 meters (33 feet) with Ecler VEO cables
AUDIO PERFORMANCES
- Audio Formats
- PCM 2Ch, LPCM 5.1, LPCM 7.1, Dolby Digital, DTS 5.1, Dolby TrueHD, DTS-HD Master Audio
- Sample Rate
- 32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
- Bit Depth
- up to 24-bit
DEVICE CONTROL
- EDID Management
- Switch
- Status Indicators
- 1 HDMI® input link indicator, 4 HDMI output link indicators, Power LED indicator
ELECTRICAL
- Power supply
- AC100-240V @ 50-60Hz Output: DC 5V-1A
- DC mains connector
- 5V DC Power Connector
- Power consumption
- 2 W Maximum
PHYSICAL
- Operating temperature
- Min: -5°C ; 41°F Max: 40°C ; 104°F
- Operating humidity
- 5 - 90% RH (no condensation)
- Included accessories
- 1 x 5V DC 1A International Power Supply
- Dimensions
- 150 x 17 x 65 mm / 5.9 x 0.67 x 2.56 in. (WxHxD)
- Weight
- 0.245 kg / 0.54 lb
- Shipping dimensions
- 220 x 60 x 190 mm / 8.66 x 2.36 x 7.48 in. (WxHxD)
- Shipping weight
- 0.6 kg / 1.32 lb
- Chassis material
- Metal
- Finished colour
- Black
