Ecler eRK108 — image 1
Commercial Loudspeakers

eRK108

8" | 2-way | 15 WRMS | IP65 | in-ground | outdoors

eRK108 is an outdoor and cost-effective ground loudspeaker, ready to be installed in gardens, theme parks, leisure facilities, etc. It features an 8" woofer, 0.5" tweeter and 70/100V transformer.

Request a quote →Chat on Zalo

Key features

01IP65 outdoor rated loudspeaker
0270/100 V (15 W)
038” woofer + 0,5” tweeter
04Stripped wire connection
05EASE files available

SYSTEM

Effective Freq. Range
35 Hz-20 kHz (-6dB)
Coverage angle / Dispersion
131°x124° (HxV)
Power handling
15 W RMS / 60 W Peak
Sensitivity
89 dB (1W/1m)
Maximum SPL
101 dB continuous / 107 dB peak
Power options (Hi Z Multi-tap)
100V: 15W 70V: 15W
Recommended amplifier power
30 W RMS

TRANSDUCERS

Ways
2 ways
Low frequency driver
8" woofer
High frequency driver
0,5" tweeter

PHYSICAL

Connection type
Stripped wire
Environmental
IP65 rated
Enclosure material
Polyresin
Operating temperature
Min: -20°C ; -4°F Max: 70°C ; 158°F
Operating humidity
<85% HR
Storage temperature
Min: -20°C ; -4°F Max: 70°C ; 158°F
Storage humidity
<90% HR
Dimensions
325 x 270 x 290 mm / 12.80 x 10.63 x 11.42 in. (WxHxD)
Weight
5 kg / 11.02 lb
Pieces per box
Unit
Shipping dimensions
300 x 340 x 280 mm / 11.81 x 13.39 x 11.02 in. (WxHxD)
Shipping weight
5.1 kg / 11.24 lb
