KICK-SB18
Subwoofers
KICK-SB18 is a wooden outdoor subwoofer reinforcement cabinet with and long-term reliability, weather protected IP46 rated. KICK-SB18 features an 8” water resistant treated woofer and 18mm Plywood birch with Polyurea coating enclosure material. It delivers 350 WRMS at 8Ω ready to be wall-mounted with the included bracket or positioned vertically and horizontally when needed.
Key features
01350W RMS @ 8Ω outdoor passive subwoofer.
021x8” water resistant treated cone woofer.
0318mm Plywood birch with Polyurea coating enclosure material.
042x SPEAKON® connectors (Input + Stack Output).
05Weather-protected with IP46 rating.
06Rubber feet for floor installation, either vertical or horizontal included.
07Wall bracket included for wall-mounted.
SYSTEM
- Effective Freq. Range
- 25Hz-4.8kHz (-10dB)
- Power handling
- 350W RMS / 1400W Peak
- Sensitivity
- 91 dB (1W/1m)
- Maximum SPL
- 116db continuous / 122dB peak
- Recommended amplifier power
- 700W RMS
TRANSDUCERS
- Ways
- Subwoofer
- Driver
- Water resistant Treated Cone
- Low frequency driver
- 1x 8" woofer
- Nominal impedance
- 8Ω
FILTERS
- Crossover filter
- No
- Recommended High-Pass protection filter
- 40 Hz with minimum 12 dB / octave filter
PHYSICAL
- Connection type
- 2 x Speakon® 4C (+1, -1)
- Installation options
- Surface, Wall mounting
- Environmental
- IP46 rated
- Enclosure material
- 18mm Plywood birch with Polyurea coating
- Grille material
- Aluminium
- Grille fixing system
- Screws
- Operating temperature
- Min: -20°C ; -4°F Max: 70°C ; 158°F
- Operating humidity
- <85% HR
- Storage temperature
- Min: -20°C ; -4°F Max: 70°C ; 158°F
- Storage humidity
- <90% HR
- Included accessories
- - 4 x Rubber foot (screws included) - 1 x Wall support system (screws not included) - 2 x Speakon®
- Finished colour
- Black (RAL 9005)
- Dimensions
- 400 x 450 x 250 mm / 15.75 x 17.72 x 9.84 in (WxHxD)
- Weight
- 14 Kg / 30.86 lb
- Pieces per box
- 1
- Shipping dimensions
- 560 x 355 x 495 mm / 22.05 x 13.98 x 19.49 in. (WxHxD)
- Shipping weight
- 17.3 Kg / 38.14 lb
