MIMO series / Digital Matrixes

MIMO1212SG

Name: Ecler MIMO1212SG
Brand: Ecler
SKU: MIMO1212SG

12x12 | digital matrix | DSP

MIMO1212SG (MIMO1212 SINGLE) is an EclerNet digital audio device that keeps the heart and soul of the standard MIMO88, its main features and its audio quality, to become a simplified and cost-effective version (12x12) of this acclaimed digital matrix.

Request a quote →Chat on Zalo

Key features

0112x12 digital matrix (not expandable)

02Fully programmable and controllable via EclerNet software

03Remotely controlled with UCPs (User Control Panels), when a UCP Server is in the system, compatible with the touchscreen WPNETTOUCH and third-party devices, such as computers, tablets, smartphones, etc.

04TP-NET protocol compatible, for third-party control systems integration

05DSP processing: signal generator, delays, full parametric EQ filters at inputs and outputs, inputs noise gate, level, mute, phase, vu-meters, outputs compressor / limiter, paging and ducking (priority & overriding), virtual and physical paging stations management, presets save & recovery, scheduled events triggering, etc.

06FREQUENCY SHIFTER function to avoid acoustic feedback, available in 4 inputs

07WPNET4KV and WPNET8K compatible control panels (using specific retro-compatible Firmware).

DIGITAL ENGINE

Processor: 2 x 32/64bit

AUDIO CONVERTERS

Sampling rate: 48kHz
Resolution: 24bit AKM
Latency: <3.2ms
Frequency response: 5Hz to 24kHz (-3dB)
Dynamic range: AD:110dB, DA: 115dB

ANALOGUE AUDIO INPUT PORTS

Number of input ports: 12, Mic/Line
Connection type: Terminal block (symmetrical)
Input sensitivity: -50dBV to +10dBV in 0.5dB step
Input impedance: Balanced, >4kΩ
Max input level: +27dBV = +30dBu
THD + Noise: THD+Noise @ 1kHz, 0dBV input (line) <0.004% THD+Noise @ 1kHz, -40dBV input (mic.) <0.008%
CMRR: 65dB typ.
Phantom power: +42VDC, 5mA max. software switched

ANALOGUE AUDIO OUTPUT PORTS

Number of output ports: 12, Line
Connection type: Terminal block (symmetrical)
Max output level: +18dBV = +21dBu
Crosstalk: Better than 90dB (100dB typ.)

CONNECTIVITY

Ethernet: 1 RJ45, Ethernet Base-Tx 10/100Mb Auto X-Over CAT5 up to 100m.
Serial port: RS-232
Programing and control: EclerNet manager (software) from v3.03r4 version, TPNET, UCP control panels
